2.5 TFSI EA855 EVO Upgrade Turbo 650-800 HP | RaceHub

2.5 TFSI EA855 EVO upgrade turbocharger

SKU: 22063In Stock
€1,000.00
1

Upgrade turbocharger for Audi RS3 8V FACELIFT TTRS 8S 2.5L TFSI STAGE 1 features:

Bolt ON (plug and play) installation;
71 mm multi-blade 0+10 high efficiency compressor wheel;
58 mm turbine wheel;
Upgraded bearing system for higher loads and performance;
Rotating parts balanced with SCHENK air bearing system balancing machine;
CHRA VSR balanced;
CNC machined enlarged compressor housing;
Genuine BorgWarner turbocharger frame;
OEM vacuum control actuator;
Power range: 650+ HP;

Upgrade turbocharger for Audi RS3 8V FACELIFT TTRS 8S 2.5L TFSI STAGE 2 features:

Bolt ON (plug and play) installation;
62/77 mm multi-blade 0+10 high efficiency compressor wheel;
60/55 mm 9 blades high flow turbine wheel;
Dual ceramic ball bearing system for high loads and performance;
Rotating parts balanced with SCHENK air bearing system balancing machine;
CHRA VSR balanced;
CNC machined enlarged compressor housing;
Genuine BorgWarner turbocharger frame;
OEM vacuum control actuator;
Power range: 700+ HP;

Upgrade turbocharger for Audi RS3 8V FACELIFT TTRS 8S 2.5L TFSI STAGE 3 features:

Bolt ON (plug and play) installation;
4” Elbow inlet pipe included;
68/79 mm multi-blade 0+9 high efficiently compressor wheel;
68/63 mm 9 blades High Flow turbine wheel;
Dual ceramic ball bearing system for high loads and performance;
Rotating parts balanced with SCHENK air bearing system balancing machine;
CHRA VSR balanced;
CNC machined enlarged compressor housing;
Custom enlarged A/R turbine housing with exhaust manifold;
Custom heat shield protection installed;
OEM vacuum control actuator;
Power range: 800+ HP

Specifications

  • Type:Bolt-on upgrade turbocharger
  • Engine:2.5 TFSI EA855 EVO
  • Stages:Stage 1, Stage 2, Stage 3
  • Power Stage 1:650+ HP
  • Power Stage 2:700+ HP
  • Power Stage 3:800+ HP
  • Compressor wheel Stage 1:71 mm, 0+10 blades
  • Compressor wheel Stage 2:62/77 mm, 0+10 blades
  • Compressor wheel Stage 3:68/79 mm, 0+9 blades
  • Turbine wheel Stage 1:58 mm
  • Turbine wheel Stage 2:60/55 mm, 9 blades high flow
  • Turbine wheel Stage 3:68/63 mm, 9 blades high flow
  • Bearing Stage 1:Upgraded bearing system
  • Bearing Stage 2 and 3:Dual ceramic ball bearing
  • Compressor housing:CNC machined, enlarged
  • Turbine housing Stage 3:Custom enlarged A/R with exhaust manifold
  • Frame:Genuine BorgWarner
  • Actuator:OEM vacuum control
  • Balancing:SCHENK air bearing and CHRA VSR balanced
  • Installation:Bolt-on, plug and play
  • Brand:RaceHub
