2.0 TFSI / TSI EA888 GEN3/GEN3B upgrade turbocharger 500+ hp

SKU: 22059In Stock
Tuning Stages
€1,590.00
1

Bolt-on solution for 2.0 TSI/TFSI EA888 GEN3/GEN3B engine, designed to work with stock exhaust manifold and other engine units. Specifications and compatibility list written below.

Power range: up to 400+ hp

Upgrade turbocharger features:

dual ceramic ball bearing
reinforced bigger machined from the solid compressor wheel - 45/60mm;
enlarged turbine wheel - 53/47mm;
special IS38 based enlarged A/R turbine housing;
new shafts;
balanced on VSR;
Power range: up to 480+ hp

Upgrade turbocharger features:

dual ceramic ball bearing;
reinforced bigger machined from the solid compressor wheel - 49/60mm;
enlarged turbine wheel - 53/50 mm;
special IS38 based enlarged A/R turbine housing;
new shafts;
balanced on VSR

Specifications

  • Type:Bolt-on upgrade turbocharger
  • Stages:Stage 1, Stage 2
  • Power Stage 1:up to 400+ HP
  • Power Stage 2:up to 480+ HP
  • Bearing:Dual ceramic ball bearing
  • Compressor wheel Stage 1:45/60 mm, machined from billet
  • Compressor wheel Stage 2:49/60 mm, machined from billet
  • Turbine wheel Stage 1:53/47 mm
  • Turbine wheel Stage 2:53/50 mm
  • Turbine housing:IS38 based, enlarged A/R
  • Shafts:New
  • Balancing:VSR balanced
  • Exhaust manifold:Stock, no modifications
  • Engines:2.0 TFSI EA888 Gen3, 2.0 TFSI EA888 Gen3b
  • Brand:RaceHub

Compatible vehicles
